3D Panel Peaks
Zintra 3D Panel Peaks is an acoustic wall panel from Zintra featuring a mountain-inspired angular profile with symmetrical pointed protrusions across each strip. Sold in sets of three strips covering 2.4 m2, it installs on straight or curved walls to absorb sound while creating a sculptural, textured surface finish.
Specifications
- Set contents: 3 strips per set
- Coverage per set: 2.4 m2 (26.3 sq ft)
- Strip dimensions: 305 mm w x 2745 mm h x 40 mm d
- Visible width per strip: 289 mm
- NRC: 0.45
- Material: 100% solution-dyed (colour-through) polyester
- Panel thickness: 12 mm
- Density: 2.4 kg/m2
- Recycled content: 60% post-consumer PET bottles, 35% pre-consumer PET chips, 5% polylactic acid (PLA)
- Delivery: ships flat-packed; two-person assembly recommended
Applications
Interior wall treatment for offices, conference rooms, contemporary residential settings, and hospitality venues where a bold geometric surface texture is desired alongside practical sound absorption. The angular peaks profile is deeper than the batten variants at 40 mm, giving stronger shadow lines. Suitable for straight and curved walls. Not suitable as a free-standing product.
Standards and compliance
ASTM E84 Class A fire classification. AS ISO 9705:2003 Group 1 fire classification. EN 13501 B-s2-d0 fire classification.
Frequently asked questions
How does the Peaks profile differ from the Batten variants?
Peaks strips are 40 mm deep compared to 37 mm for the Batten range, and the surface texture is angular and pointed rather than flat-faced with vertical battens. Coverage per set is 2.4 m2 versus 2.5 m2 for Batten 4 and Batten 6. All variants achieve NRC 0.45.
Is the NRC the same as the Batten variants?
Yes. The Peaks panel achieves NRC 0.45, the same rating as the Batten 2, Batten 4, and Batten 6 variants in the 3D panel range.
What colour options are available?
Peaks panels are available in the full Zintra 12 mm solid PET colour range, which includes options such as Bark, Frost, Midnight, Ochre, Pebble, Smoke, and others. Colour runs through the full depth of the material.
Click here to download the Data Sheet
Click here to download Installation Guide 1
