L-Acoustics - K1
The L-Acoustics K1 is a large-format line array enclosure designed for stadium concerts, major touring productions, and outdoor festivals. Its three-way active configuration delivers 149 dB maximum SPL across a 35 Hz to 20 kHz bandwidth, making it the primary choice for the highest-demand live sound applications.
Specifications
- Configuration: 3-way active line array enclosure
- Max SPL: 149 dB (at 1 m, free field)
- Bandwidth: 35 Hz to 20 kHz
- LF transducers: 2 x 15 inch neodymium cone drivers
- MF transducers: 4 x 6.5 inch neodymium cone drivers
- HF transducers: 3 x 3 inch diaphragm compression drivers
- Horizontal directivity: 90 degrees symmetric
- Vertical directivity: 5 degrees (array-dependent)
- Amplification: Quad-amplified by LA12X amplified controller
- Inter-enclosure angles: 0 to 5 degrees in multiple increments
- Dimensions (H x W x D): 1342 x 438 x 520 mm
- Weight: 106 kg / 234 lb
- Cabinet: Baltic birch plywood with polyethylene coating
- Connectors: 2 x 8-point PA-COM
Applications
The K1 is deployed in stadium-scale touring productions, major outdoor festivals, and large arena events. It is used as the primary hang in configurations requiring maximum throw distance and high SPL with controlled vertical coverage. Arrays are commonly combined with K1-SB subwoofers for extended low-frequency output.
Frequently asked questions
What amplification does the K1 require?
The K1 is quad-amplified and requires the L-Acoustics LA12X amplified controller for full system operation.
How many inter-enclosure angle options are available?
The K1 supports multiple inter-enclosure angles from 0 to 5 degrees, allowing flexible vertical coverage shaping across different venue geometries.
What is the cabinet construction?
The K1 enclosure uses premium Baltic birch plywood with a polyethylene coating for protection during touring use.
