Prisma-KPRA04+
The Prisma-KPRA04+ is a compact amplified matrix platform from K-Array, pairing the Integrated Electronic Brain-Pro (IEB-Pro) processor with a four-channel Class D power amplifier rated at 150 W per channel. It accepts analog and digital inputs, supports Dante-Ready networking, and provides onboard DSP in an aluminium chassis suited to medium fixed installations requiring more output power than the KPRA02+.
Specifications
- Type: Amplified matrix with IEB-Pro, 4-channel analog inputs and 4-channel powered outputs
- Output power: 4 x 150 W at 4 ohm
- Amplifier class: Class D switching mode
- Minimum impedance: 4 ohm
- Frequency response: 20 Hz to 20 kHz (+/-1 dB)
- Dante channels: Up to 8 x 8 (Dante-Ready, license activation required)
- Analog inputs: 4 x balanced via Phoenix MC 1.5/3-ST-3.81 connector (plus K-PREAMPS4 module), 1 x 3.5 mm unbalanced stereo AUX, 1 x TOSLINK optical
- Digital connectivity: 4 x USB-A 2.0, 2 x RJ45 Ethernet, Wi-Fi IEEE 802.11 b/g/n
- Power: 1 x PowerCon TRUE IN
- Built-in DSP: Grouping, equalisation, limiters, routing, level control, loudspeaker presets
- Remote control: Wi-Fi and Ethernet, dedicated app and desktop software
- Mains input: 100 to 240 V AC, 50/60 Hz with PFC
- Power consumption: 150 W at 8 ohm, pink noise, 1/4 rated power
- IP rating: IP20
Applications
Suited to conference rooms, corporate AV, retail spaces, and hospitality installations where a compact amplified matrix with moderate power output is required. The integrated Wi-Fi alongside wired Ethernet control, optical and balanced analog inputs, and Dante networking capability provides flexible connectivity for a variety of system architectures.
Frequently asked questions
How does the Prisma-KPRA04+ differ from the KPRA02+?
The KPRA04+ delivers 150 W per channel at 4 ohm compared to 50 W per channel for the KPRA02+. It also connects to mains via a PowerCon TRUE IN connector rather than an external DC adapter, and includes Wi-Fi IEEE 802.11 b/g/n alongside wired Ethernet.
Is Dante networking enabled out of the box?
The unit is Dante-Ready and supports up to 8 x 8 Dante channels, but a Dante license activation is required before network audio functionality is available.
What output connector type does the KPRA04+ use?
The output connector type for the four amplified channels is not specified in the available technical data. The KPRA02+ variant uses Euroblock connectors; consult the datasheet for the KPRA04+ output connector specification.
