Dragon-KX12 I
The Dragon-KX12 MKI delivers a fresh take on the legendary KX12, offering a radical reinterpretation of a coaxial point source speaker. Featuring a 12” woofer and a 1.7” compression driver, this speaker is designed to elevate high-quality audio experiences. It excels both as a powerful point source and as part of a line array, providing exceptional versatility for various applications.
The MKI version introduces a sleek stainless steel chassis with a compact and lightweight design. This not only enhances durability but also simplifies rigging and installation, making it an ideal choice for demanding environments.
Built to handle high-intensity applications, such as DJ monitoring in exclusive venues, the KX12 MKI features a fixed waveguide that can be rotated with screws to achieve focused or spread horizontal and vertical coverage of V. 40° | H. 60°. This design optimizes sound dispersion for superior performance. When used in an array, the speaker takes full advantage of EBS (Electronic Beam Steering) technology, allowing for precise, electronically adjustable coverage and ensuring consistent, controlled sound distribution.
Specifications
- Type: Point source
-
Transducers:
- Coaxial 12" woofer
- 1.7" compression driver
- Frequency Response: 120 Hz - 18 kHz (-6dB) (1)
- Max SPL: 133 dB (peak) (2)
- Rated Power: 800 W
- Coverage: Vertical 40° | Horizontal 60° (rotatable with screws)
-
Connectors: 2 x SpeakOn NL4
- 1+ 1- (signal)
- 2+ 2- (through)
- Nominal Impedance: 8Ω
Handling and Finishes
- Dimensions (W x H x D): 350 x 350 x 203 mm (13.8 x 13.8 x 8 in)
- Weight: 15 kg
- Material: Stainless Steel
- Colors: Black, Custom RAL
Regulations
- IP Rating: IP54
Notes:
(1) With dedicated preset.
(2) Maximum SPL is calculated using a signal with crest factor 4 (12dB) measured at 1 m.
Disclaimer: New materials and designs may be introduced without prior notice.
